Red Lion EtherTRAK-2 E2-32DO24-D — 32-Channel Digital Output Remote I/O Module
The Red Lion EtherTRAK-2 E2-32DO24-D is a rugged remote I/O module providing 32 digital outputs (10–30 VDC, 0.5 A per channel). Built for industrial Ethernet networks, it features dual Ethernet ports (2 × RJ45) with ring-switch / RSTP support, plus RS-485 and USB connectivity.
Supporting Modbus TCP, Modbus RTU/ASCII and Sixnet protocols, the module integrates seamlessly with PLCs, SCADA and Red Lion controllers. With DIN-rail mounting, wide -40 to +75 °C operation and self-resetting short-circuit protection, it is a reliable choice for distributed machine and process I/O.
Your Benefits at a Glance
- 32 digital outputs (10–30 VDC, 0.5 A/ch) — high-density switching
- Dual Ethernet + RSTP ring support — network redundancy
- Modbus TCP / RTU / ASCII & Sixnet — universal protocol compatibility
- RS-485 + USB ports — flexible integration and configuration
- Self-resetting fuses — short-circuit protection
- DIN rail mounting, -40…+75 °C — industrial-grade ruggedness
- Web-based configuration — fast setup
Technical Specifications
表格
| Item | Specification |
|---|---|
| Manufacturer | Red Lion Controls (HMS Networks) |
| Series | EtherTRAK-2 |
| Model | E2-32DO24-D |
| Type | Remote I/O module — digital outputs |
| Outputs | 32 × digital output, 10–30 VDC, 0.5 A/channel (8 A/module) |
| Supply Voltage | 10–30 VDC |
| Communication | 2 × Ethernet (RJ45), RS-485, USB; Modbus TCP / RTU / ASCII, Sixnet |
| Network Features | Dual IP, RSTP ring support |
| Protection | Self-resetting fuses (trip >1.5 A) |
| Operating Temperature | -40 to +75 °C |
| Mounting | DIN rail |
| Status | Discontinued by manufacturer — supplied as spare part / refurbished |
Note: Verify firmware, protocol and power requirements with your control system before ordering.
Typical Applications
- Distributed machine and process I/O
- PLC / SCADA remote output expansion
- Material handling and packaging lines
- Replacement and retrofit of EtherTRAK-2 modules
