Kollmorgen 446M-C belongs to SERVOSTAR S400 series high-performance digital servo amplifier. It is the master version of S400 drive, equipped with expansion slot for optional communication cards. It supports analog and digital control, compatible with Kollmorgen synchronous servo motors. Compact 70mm width cabinet design, suitable for retrofitting and maintenance of old production machinery.

Key Features

• Master servo drive of S400 series, expansion slot for fieldbus cards
• Optional communication: Profibus DP, SERCOS, DeviceNet, EtherCAT
• Built-in 2 analog inputs and multi programmable digital I/O
• Integrated RS232 debugging port, easy parameter setup
• Integrated restart lock safety function, comply with EN 60204
• Support position, speed and torque closed-loop control
• Stable four-quadrant operation with dynamic braking
• Compact 70mm width design, save cabinet installation space

Applications

Legacy CNC machine tools, printing machinery, textile equipment, packaging machines, automated assembly lines and other precision motion control equipment.

Specifications

Brand: Kollmorgen Model: 446M-C Series: SERVOSTAR S400 Type: Single Axis Digital Servo Amplifier (Master Unit) Width: 70mm Communication: Support Profibus DP, SERCOS, DeviceNet, EtherCAT via expansion card Interface: 2 Analog inputs, RS232, Digital I/O Safety: Integrated restart lock, EN 60204 compliant
