The Allen-Bradley 2711P-T19C22D9P-B terminal is a Panelview Plus 7 series performance edition interface terminal that is brandless. Because this terminal does not come with the Allen-Bradley brand name or logo printed on it, the users can label the terminal with their own brand name and logo. The 2711P-T19C22D9P-B interface terminal is powered by 18 to 30 Volts DC of input voltage and 24 Volts DC of nominal voltage. It is controlled through a 19-inch touchscreen that supports color graphics. The 2711P-T19C22D9P-B interface terminal has a conformal coating for protection against corrosion and 512 MB each of RAM and storage memory.
Technical specifications for 2711P-T19C22D9P-B
| Manufacturer | Allen Bradley |
|---|---|
| Category | Panelviews |
| Product Line | Panelview Plus 7 |
| Part Number | 2711P-T19C22D9P-B |
| UPC | 885630844961 |
| Weight | 20.00 lbs (9.07 kg) |
| Input Type | Touchscreen |
| Display Size | 19 in. |
| Display Color | Color |
| Memory | 512 Mb |
| Input Voltage | 24 VDC |
| Backlight | LED |
Description
The Allen-Bradley PanelView™ Plus 7 (2711P-T19C22D9P-B) is a real-time monitoring module. The 2711P-T19C22D9P-B has a display size of 19-inches and the display is a touchscreen. This module is the brandless version. Operators can control it easily because the 2711P-T19C22D9P-B is user-friendly. This module has a replaceable battery and the battery life of this module is around four years minimum at 25 °C. Remove the power when you want to remove or replace the battery. This module has a flash memory of 1 GB and 512 MB of RAM (with 80 MB of free user memory). It also has a Secure Digital (SD) card slot. The Allen-Bradley 2711P-T19C22D9P-B also follows some Electromagnetic Compatibility (EMC) standards. The 2711P-T19C22D9P-B has passed EN 50081-2 EMC - Generic Emission Standard, Part 2 - Industrial Environment. This module has passed EN 50082-2 EMC – Generic Immunity Standard, Part 2 - Industrial Environment. The Allen-Bradley 2711P-T19C22D9P-B has an operating shock of 15 g (3 pulses, 11 ms). The nonoperating shock of the module is 30 g (3 pulses, 11 ms). This module is designed to maintain an optimum functionality at 2.5 g vibration. This module can operate at altitudes of up to 2000 m without derating. The module’s relative humidity is 5-95% without condensation, the operating temperature is 0-55 °C (32-131 °F), and the storage temperature is -40-70 °C (-40-158 °F).
