The Allen-Bradley 2711P-T7C22D8S is a PanelView Plus 7 Standard operator terminal. This Human Machine Interface (HMI) device is powered by an external supply voltage of 18-30VDC. It has a 6.5-inch Color active matrix, thin-film transistor (TFT) LCD with embedded Touchscreen operator interface. It has a variety of communication ports such as, Two (2) Ethernet and Two (2) USB ports.
Technical specifications for 2711P-T7C22D8S
| Manufacturer | Allen Bradley |
|---|---|
| Category | Panelviews |
| Product Line | Panelview Plus 7 |
| Part Number | 2711P-T7C22D8S |
| UPC | 885630920436 |
| Weight | 2.00 lbs (0.91 kg) |
| Display Size | 6.5 inches |
| Product Family | PanelView Plus 7 Standard terminals |
| Operator Input | Touch |
| Display Type | Color active-matrix TFT |
| Display Area | 132 x 99 mm |
| Resolution | 640 x 480 VGA, 18-bit color graphics |
| Touch | Analog resistive Actuation: 1 million presses; operating force: 100 g |
| System Memory | 512 RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory) |
| Communication ports | Two (2) Ethernet, Two (2) USB host |
| Input Voltage range | 18-30 VDC |
| Power Consumption | 50 W max (2.1 A at 24V DC) |
| Backlight | White light-emitting diode, solid state Life: 50,000 h min at 40 °C (104 °F) to half-brightness, backlight is not replaceable |
| Input Type | Touchscreen |
| Display Color | TFT Color Display |
| Memory | 512 Mb |
| Input Voltage | 24 VDC |
Description
The 2711P-T7C22D8S terminal is a standard graphics display terminal. Allen-Bradley is the manufacturer of this graphics terminal, which belongs to the PanelView Plus 7 series. The terminal comes with a touchscreen interface and 6.5-inch display with 640 x 480 pixel resolution and aspect ratio of 4:3.
The 2711P-T7C22D8S terminal needs a relatively humid environment with 5 to 95% non-condensing relative humidity. It is a 6.5-inch terminal with physical dimensions of 6.69 x 8.35 x 2.74 inches. The terminal comes with a functionality that permits connection to 1 controller and up to 25 screens, and it has support for up to 200 alarms.
It also comes with Ethernet ports for controller communication which supports device-level ring network topology. The touchscreen of the display provides accurate, reliable, and durable touch control for modern industrial applications. The touchscreen of the 2711P-T7C22D8S terminal also supports gesture control for interacting with the screen elements. The display terminal has been manufactured to be used in a Pollution Degree 2 rated industrial environment with overvoltage Category II applications as defined in the IEC 60664-1 publications. The panel can be used at an altitude of up to 2000 meters above sea level without any degrading in its performance. The 2711P-T7C22D8S terminal meets the specified NEMA, UL, and IEC ratings when it is mounted in a panel or enclosure.
This provides the runtime environment serving as the terminal’s operator workspace.
Basic features of the 2711P- T7C22D8S include a 7-inch, colored TFT LCD screen with resolution of 640 x 480 VGA that support 18-bit color graphics, viewing area of 132 x 99 mm with aspect ratio of 4:3. The provided operator input area is the analog resistive touchscreen interface that is designed to be actuated up to 1 Million actuations. This controller is compatible with Allen-Bradley’s CompactLogix and ControlLogix controllers. Communication and data exchange is executed through the dual Ethernet communication interfaces which may be implemented in Linear, Star and Device Level Ring (DLR) topologies.
