The Allen-Bradley 2711-K5A2 is a Panelview 550 Standard Operator Terminal. This operator terminal is powered by an external 85-264V AC supply voltage and has a 5.5-inch monochrome display with embedded DH485 communication port. It has Ten (10) Function keys and a Keypad operator interface.
Technical specifications for 2711-K5A2
| Manufacturer | Allen Bradley |
|---|---|
| Product Type | PanelView 550 Standard Operator Terminals |
| Product Line | Panelview 550 |
| Part Number | 2711-K5A2 |
| UPC | 662468332699 |
| Weight | 2.63 lbs (1.19 kg) |
| Backlight | 100,000 hr LED backlight life |
| Product Family | PanelView Standard Operator Terminals |
| Operator Input | Keypad |
| Display Type | Monochrome transflective LCD with LED backlight |
| Display Area | 120 x 60 mm (4.75 x 2.38 in.) |
| Resolution | 256 x 128 |
| Keypad Assembly | 10 function keys (F1…F10) |
| Application memory | 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Communication ports | DH485 |
| Input Voltage range | 85…264V AC |
| Input Frequency | 47…63 Hz |
| Enclosure | NEMA Type 12/13, 4X (Indoor use only), IP54, IP65 |
| Status Indicators | COMM: Green Fault: Red |
| Display Size | 5.5 inches |
| Display Color | Monochrome LCD blue mode |
| Input Type | Keypad(F1-F10) |
| Communication | DH-485 Communication Ports |
| Input Power | 120 Volts AC |
| Memory | 170 KB application runtime |
| Communication Cable | 1747-C10 |
| Series | A,B,C,D,E,F,G,H |
| UNSPSC | 43211902 |
Description
The 2711-K5A2 is an Allen-Bradley PanelView Standard operator terminal that features an integrated keypad input interface, display area, communication port and internal memory. This electronic device has a compact assembly that support flush mounting to an industrial rated enclosure.
The 2711-K5A2’s keypad input interface is composed of Ten (10) function keys that accepts local and global assignments, making any button usable for a specific function or accept variable assignment. Aside from the function keys, the keypad assembly also has a numeric key set for entering numerical variables and constants; Navigation keys to highlight appropriate objects displayed in the screen.
This operator terminal also has a 5.5-inch monochrome screen with display area of 120 x 60 mm (4.75 x 2.38 in.) and resolution of 256 x 128 pixels. It comes with a replaceable internal backlight that is designed to operate up to 100,000 hrs.
This shortens and maximizes engineering time as internal tests may also be done without the need of the physical hardware.
The 2711-K5A2 has an internal Random Access Memory (RAM) amounting to 170KB and a non-volatile memory with size of 240KB which is used to save applications and system files such as trends, logs and user manuals.
The 2711-K5A2 is installed to a NEMA or IP rated enclosure that offers adequate protection against water ingress, dust, dirt, corrosive and explosive substances. Install the 2711-K5A2 in a NEMA Type 12/13, 4X (Indoor use only), IP54 and IP65 or any equivalent rated enclosures.
The 2711-K5A2 is an Allen-Bradley PanelView 550 terminal. This obsolete operator terminal allows user to interface with other machines. This PanelView device has a 5.5 in. monochrome LCD blue mode screen. It has an embedded DH-485 communication port. The user is able to control the unit by using the embedded keypad located at the device’ front panel.
Its DH-485 communication port can connect to SLC and MicroLogix controllers, a DH-485 network, or to a Wallmount Power Supply. The 2711-K5A2 terminal is powered using 120 Volts of AC power. This unit has 170 KB of application runtime memory and 240 KB of nonvolatile memory. This unit has an internal backlight replacement part number of 2711-NL1. The approximate shipping weight and dimensions of the terminal are 6 pounds and 14 x 11 x 8 inches, respectively.
