The 22F-A8P0N103 is part of the PowerFlex 4M adjustable frequency AC drive. These drive series are cost-effective, compact drives that are specially designed for use with motors that drive light or medium loads. The 22F-A8P0N103 electrical features include an input voltage rating of 200-240 VAC, 1-Phase, and an input current of 22.3 Amperes. It has an output voltage of 0-230 VAC, 3-Phase, output current, and power of 8.0 Amperes and 2.0 HP or 1.5 kW. The 22F-A8P0N103 is ideally used for speed control as it supports a single control method that is Volts per Herts (V/Hz) control however, this drive also supports soft-starter capabilities which can be used to provide efficient starting and stopping characteristics. Configurable starting and stopping functions include Ramp, Coast, DC-Brake, Ramp-to-Hold, and S-curve as well as Acceleration and Deceleration times. The 22F-A8P0N103 has built-in protection features such as Intermittent Overload, class 10 motor overload protection, Bus Overvoltage, and Undervoltage protection. The built-in I/O channels to the 22F-A8P0N103 are comprised of Five (5) 24 VDC discrete inputs, Two (2) analog input, and Two (2) Form C relay output while the embedded communication interface is an RS485 port that supports Modbus RTU and Drive Serial Interface (DSI) protocol. Communication options available to the 22F-A8P0N103 include EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP communication interface modules. The drive’s local configuration and operation can be carried out via the built-in keypad assembly that functions as the Human Interface Module (HIM).

The Allen-Bradley 22F-A8P0N103 PowerFlex 4M AC Frequency Drive is a 240V AC (1-Phase) variable frequency drive that provides a control for the machine speed of industrial motors. Its operating voltage is 180-265V AC at 50-60Hz, with an output current of 8A and a power output of 1.5kW (2HP). It has a real power usage of 5.4KVA with a 22.3A input current. Recommended branch circuit protection is 35 Class J fuses with the 140M-D8E-C25 motor protector and the 100-C23 circuit contactor. It has 5 digital control inputs with the source mode (18-24V/0-6V ON/OFF) and the sink mode (0-6/18-24V ON/OFF) which are both user selectable with a DIP switch and a single 0-10V DC/4-20mA Analog input with 100 K Ohms/250 Ohms loads. The 22F-A8P0N103 has a Form C relay output, with 3A resistive rating and a 0.5A inductive rating at 30V DC, 125V AC, but it has no safety input option. It has a 200% hardware limit, and 300% instantaneous fault overcurrent protection, with a motor overload protection rate of 150% for 60 seconds and of 200% for 3 seconds, and it provides a BUS overvoltage trip of 405V and an Undervoltage trip of 210V. It has a programming panel with a multi-lingual LCD display quick-view scrolling text keys and a fixed keypad, and it comes with an integral RS485 (Modbus RTU) communication port and optional DeviceNet, EtherNet/IP, ControlNet, and Bluetooth communication options. The drive can be panel mounted, and it comes in an IP20-rated enclosure. It has a working temperature range around 14-122 oF, at 0-95% non-condensing relative humidity, and it can be stored at a temperature range around -40-185 oF. The 22F-A8P0N103 has 1000m of maximum working height, without de-rating, and it weighs approximately 1.6Kg (3.5lb), with total dimensions of 72mm x 174mm x 136mm.
