The 22F-D024N114 drive is an AC drive from the Allen-Bradley/Rockwell Automation PowerFlex 4M drive series. It comes with a Size C frame and with an EMC filter. The 22F-D024N114 AC drive requires 3-phase AC voltage for both its input and output voltage. Its 3-phase AC input voltage rating is 380 to 480 Volts AC (+/-10%) and its 3-phase AC output voltage rating is 0 to 460 Volts AC with the filter. The 22F-D024N114 AC drive supports an output current rating of up to 24 Amps.
Technical specifications for 22F-D024N114
| Manufacturer | Allen Bradley |
|---|---|
| Category | Drives |
| Product Line | PowerFlex 4M |
| Part Number | 22F-D024N114 |
| UPC | 820919785313 |
| Weight | 3.63 lbs (1.64 kg) |
| Amperage | 24 |
| Wattage | 11 Kilowatt |
| Enclosure Type | Open- IP20 |
| Input Power | 480 Volts- Alternating Current |
| Phase | Three-Phase |
| Filter | With Internal CE Compliant Filter |
| Horsepower | 15 Horsepower |
| Communication | RS-485 Port |
Description
The Allen-Bradley 22F-D024N114 is a PowerFlex 4M 3-phase, low-voltage AC drive that comes with an integral “S Type” EMC filter, an IP20 enclosure rating, and a C frame size. Its voltage rating is 480V AC, its input ratings are 340-528V, 21.7 kVA, and 26.1 A, and its output ratings are 24 A, 11 kW, and 15 HP. The maximum surrounding air temperature this drive can operate at is -10-40 oC and the non-operating air temperature is -40-95 oC. It also has a maximum operating altitude of 1000 m without derating and a non-condensing humidity range of 0-95%. The operating vibration of this drive is 1 g peak at 5-2000 Hz, while its operating shock is 15 g peak for 11 ms (+/- 1 ms).
This drive also has a standard internal IGBT brake installed and it is panel-mounted. It is important that you install the 22F-D024N114 drive in an area with an ambient atmosphere that does not have any dust, vapor, or volatile gas, nor should it be stored in a corrosive environment.
Suitable for open loop speed regulation applications, this drive features a 4-digit display, remote and local keypad input with arrow keys and function keys, and 10 LED status indicators. Its built-in speed potentiometer is used to control the drive speed and it features a "volts per Hertz" motor control. The I/O present on this drive are 1 analog PTC input, 1 unipolar voltage input, 5 24V DC digital inputs with 2 of them programmable, and 1 form C relay output.
