The Allen-Bradley 22C-D030F103 drive is an adjustable frequency drive from the PowerFlex 400 series of fan and pump control drives. It is designed to be able to handle a wide variety of fan and pump control applications in industrial environments. The 22C-D030F103 adjustable frequency drive is rated for 380 to 40 Volts AC 3-phase input voltage at a frequency range between 50 and 60 Hertz. It can be mounted on a flange and protected by an IP 20 rated open enclosure. The 22C-D030F103 adjustable frequency drive needs a DC series bus inductor device to be connected to it before it can be operated.
Technical specifications for 22C-D030F103
| Manufacturer | Allen Bradley |
|---|---|
| Category | Drives |
| Product Line | PowerFlex 400 |
| Part Number | 22C-D030F103 |
| Weight | 12.00 lbs (5.44 kg) |
| Drive Type | Fan & Pump |
| Horsepower | 20 |
| Input Voltage | 480 Volts AC |
| Phase | Three-Phase |
| Enclosure | Flange Mount - IP20, NEMA/UL Type Open |
| Amperage | 30 Amps |
Description
The Allen-Bradley 22C-D030F103 is a PowerFlex 400 AC drive boasting an output of 15 kW or an equivalent of 20 HP. It is an IP20, NEMA/UL Type 1 enclosure device. It is also a flange device with 380-480V AC input voltage and 200-240V AC power that allows its heatsink at the rear enclosure to run. The 22C-D030F103 is rated for both indoor and outdoor use. This part features an in-built auxiliary motor control that aids in the control of three-phase motors together with motors under direct control from the device. It also allows for damper control logic, which is embedded into the system and reduces drive costs. The 22C-D030F103 has an input that can be connected to a wire control panel or to any fire safety system, which may enable the overriding of the device if the need arises. Using its digital inputs, it is easy to perform digital programming, which ensures good user interaction.
The 22C-D030F103 features an operator keypad and programming display panel that makes it easy to key in data and information. The user interface is aided by the keypad that features a 2-line x 16-character LCD. The LED indicators help to warn when the system has issues. It supports the Drive Serial Interface (DSI) communication modules such as the Ethernet Profibus and the LonWorks. Its integral RS485 communication capability can be used to support personal computer programming. Its serial converter module helps to link activity to any controller with a DF1 port. The 22C-D030F103 features an in-built Proportional Integral Differential (PID) loop that aids in maintaining parameters such as pressure and flow at the wanted level.
