The 2080-LC20-20AWBR controller is an Allen-Bradley/Rockwell Automation programmable controller from the Micro 820 series. It has 20 total input and output points. The 2080-LC20-20AWBR programmable controller?s inputs and outputs include 8 AC inputs, 4 DC inputs, 7 relay outputs, 1 analog output, and 4 analog inputs. The 8 AC inputs are rated for 120 Volts AC voltage and the 4 DC inputs are rated for 24 Volts DC. The 2080-LC20-20AWBR programmable controller has an IP 20 environmental protection rating.
Technical specifications for 2080-LC20-20AWBR
| Manufacturer | Allen Bradley |
|---|---|
| Product Type | Programmable Controller |
| Product Line | Micro 820 |
| Part Number | 2080-LC20-20AWBR |
| UPC | 885630807065 |
| Weight | 3.00 lbs (1.36 kg) |
| Inputs | 8(120V AC); 4(24V DC) |
| Outputs | 7(Relay); 1 (Analog Out) |
| Power Input | 24V DC |
| Power Dissipation | 6 W |
| Power Supply Voltage Range | 20.4-26.4V DC, Class 2 |
| Enclosure | Meets IP20 |
| AC Input On-state Voltage max. | 125V AC |
| Relay Output Voltage min. | 5V DC/ AC |
| Relay Output Voltage max. | 250V AC |
| Pilot Duty Rating | C300, R150 |
| Terminal Block | Removable |
Description
The Allen-Bradley 2080-LC20-20AWBR is a controller in Allen-Bradley’s Micro 820 series. It possesses 8 110-240V AC inputs, 4 24V DC inputs, 7 relay outputs, 4 configurable analog inputs, and 1 analog 0-10V DC output. The 2080-LC20-20AWBR can communicate with other machines through its communication ports which include 2 plug-in slots, a MicroSD Card port, an RS-232/485 non-isolated serial port, an embedded Ethernet port, and RTB terminals. Note that the MicroSD port is meant for Class 6 and Class 10 SCSC and SDHC microSD cards, but not Class 4 microSD cards. These cards can backup and restore projects, log data and recipes, and configure the 2080-LC20-20AWBR’s power-up settings. Do not connect the 2080-LC20-20AWBR controller to an EtherNet/IP network while the controller is powered on.
You can mount the 2080-LC20-20AWBR controller in a 3.94 x 3.39-inch panel mount. Its other convenient features include a real-time clock that does not need a battery and Ethernet/IP connectivity for RTU applications, application programming, and Human-Machine Interface (HMI) capability.
The 2080-LC20-20AWBR controller is hazardous-location approved for use in North America. Make sure to mount it in the proper type of enclosure for the type of location it is going to operate in. Also, make sure to wire it properly and keep corrosive chemicals away. If you attempt to connect or disconnect the 2080-LC20-20AWBR to a removable terminal block, serial cable, or a communication cable, an electrical arc may occur which may damage the controller or injure you.
