The Allen-Bradley/Rockwell Automation 1606-XLS480G power supply module is a single-phase type of power supply module and it is available from the Allen-Bradley 1606-XLS series of industrial power supplies. One of the key features of the 1606-XLS480G power supply module is its synchronous rectification technology that gives it both a high degree of efficiency and a small size. This power supply can be mounted on a DIN Rail. The AC input voltage range of the 1606-XLS480G power supply module is 100 to 240 Volts AC, and the DC input voltage range is 110 to 300 Volts DC. This power supply module also has a wide operating temperature range from -25 to 70 degrees Celsius.
Technical specifications for 1606-XLS480G
| Manufacturer | Allen Bradley |
|---|---|
| Product Type | Switched Mode Power Supply |
| Product Line | 1606 Switched Mode Power Supplies |
| Part Number | 1606-XLS480G |
| UPC | 612598713271 |
| Weight | 2.13 lbs (0.96 kg) |
| Input Voltage | 100-240V AC |
| Output Power | 480W |
| Output Current | 13.3A |
| Terminals | Spring Clamp |
| Signal | DC-OK |
| Output Voltage | Adjustable |
| Size | Compact |
| Heat Generation | Minimal |
Description
The 1606-XLS480G power supply is a small Allen-Bradley 1606-XLS power supply that comes with extra-low inrush current. The 1606-XLS480G power supply delivers active power factor correction and has a wide range of AC/DC input. The 1606-XLS480G power supply is designed to deliver a superior level of reserve power and it can support 150% rated power for up to 5 seconds. The unit is designed to deliver superior efficiency and temperature ratings. It supports synchronous rectification with innovative design features. The 1606-XLS480G power supply features the DC-OK signal and the output voltage is adjustable. It comes with a compact size and a design that helps to minimize heat generation. The 1606-XLS480G power supply is built with the spring clamp input/output terminals for a quick connection process. Therefore, there are no special tools required for connecting the unit to other devices. The quick-connect spring-clamp terminal features a positive output pole and a negative output pole.
For up to 4 seconds of overloading, the Allen-Bradley 1606-XLS480G power supply delivers a continuous output current. The output power is then reduced to nearly zero for the next 17 seconds before a new start attempt is automatically performed. The 1606-XLS480G power supply will operate normally again when the overload is cleared. If the overload persists, the output current is then delivered for 2 to 4 seconds. The 1606-XLS480G power supply used LED lights to indicate the status of its applications, and this makes monitoring the unit easy. The unit is suitable for operation in industrial environments and it is also suitable for use in residential and light industrial environments.
