The Allen-Bradley 22F-D013N104 device is a compact and efficient AC drive which provides users with powerful motor speed control. It is part of Allen-Bradley’s PowerFlex 4M series of AC drives. The PowerFlex 4M drives are ideal for controlling machine speed. These drives provide the application adaptability that can meet the demands of customers who require compact and convenient AC drives. The PowerFlex 4M AC drives are the smallest and most cost-effective member of the PowerFlex family.

On the input side, the 22F-D013N104 supports 3-phase voltage at 340-528V AC, a 12.9 KVA apparent power, and a maximum current of 15.4 Amps. It can also hand 50-60 Hz line frequencies. The 3-phase output of the 22F-D013N104 is rated at 13 Amp and 5.5 KW or 7.5 HP. The 22F-D013N104’s integrated keypad makes out-of-the-box operation possible by using the drive’s local potentiometer and control keys. It also has a 4-digit display with 10 additional LED indicators to provide a convenient display of the drive’s information and status. The integrated RS-485 serial communications port can connect to a PC for programming. The 22F-D013N104 can also be part of a multi-drop network configuration because its serial converter module provides connectivity to any controller that has a DF1 port. The 22F-D013N104’s features that provide protection and improve performance include 25 fuses for branch circuit protection, a relay pre-charge that limits the inrush current, and an integral brake transistor that provides dynamic braking with simple and economical brake resistors. The 22F-D013N104’s can handle a 200% overload for 3 seconds or a 150% overload for 60 seconds with its robust overload protection. Its adjustable PWM frequency of up to 10 kHz ensures quiet operation. The 22F-D013N104 provides good speed regulation and high torque levels across the drive’s whole speed range, and improved speed regulation even when its load increases. The dimensions of the 22F-D013N104 drive are 260 x 130 x 180 mm and it weighs 4.8 Kg.

The Allen-Bradley 22F-D013N104 is a PowerFlex 4M adjustable frequency AC drive. This drive is capable of Volts/Hertz (V/HZ) control for implementing speed control of the connected AC motor.

The 22F-D013N104 has input properties of 340-528 Volts AC, 3-Phase; 12.9 kVA and an input current of 15.4 Amperes. It delivers an output voltage of 0-460 Volts AC, 3-Phase, output current of 13.0 Amperes, output power of 7.5 Horsepower or 5.5 Kilowatts and output frequency of 0-400 Hertz, programmable with efficiency of 97.5%.

The 22F-D013N104 has an overvoltage rating of 810 Volts DC bus voltage (equivalent to 575 Volts AC incoming line) and under voltage trip of 390 Volts DC bus voltage (equivalent to 275 Volts AC incoming line). The drive’s control ride through is 0.5 seconds to 2 seconds while the faultless ride through is 100 ms. Additionally, this drive has an overcurrent rating of 200% hardware limit and 300% instantaneous fault. It also has a Class 10 overload protection which is 150% for 60 seconds and 200% for 3 seconds.

The 22F-D013N104 has an integral IGBT brake mechanism installed as well as embedded I/O for terminating external signals. Embedded I/O channels are five (5) discrete inputs; one (1) Form C relay output; one (1) 0-10 Volts DC and one (1) 4-20 milliamperes input and one (1) 1-10 kOhm potentiometer input. This drive supports sink and source wiring configuration which can be set by triggering the embedded DIP switch.
